R-22D Molex Sensor

R-22D Molex Sensor


Analytical Industries



Technical Specifications

Measuring Range 0-100%
Accuracy 1 +/-2% of Full Scale
Signal Output 2 8.5-14 mV
Linearity +/-2% of Full Scale
Response T90 6 sec
Temp Coefficient Compensated
Operating Temp 0 to 45°C
Recommended Storage 3 0 to 25°C
Qualified at 1.8 ATA
Shelf Life 4 6 months
Humidity Non-condensing 0-99% RH
Expected Life 42 months
Warranty 5 12 months
Electrical Conn 3 Pin Molex

* Conditions – Specification validated during design and in pursuit of improvement are subject to change without notice

  1. At constant temperature and pressure.
  2. In air (20.9% oxygen) at 25°C and 1 atm.
  3. Sensor may be stored up to 55°C on an intermittent basis, for example, during transportation.
  4. In original Package at 25°C and 1 atm.
  5. Under normal operating conditions, the sensor is warranted to be free of defects in material and workmanship for the specified period provided the sensor is properly installed and operated. The sole remedy for sensor determined to be defective by Analytical Industries Inc. is limited to replacing the sensor. Analytical Industries Inc. will not be liable for buyer’s negligence, misapplication, abuse or accident.


Analytical Industries
